Circle Single lever bathtub mixer for exposed installation

Single lever bathtub mixer for exposed installation, CE5230000010 Chrome, Connection type for water supply connection: S-connections, Centre distance: 150 mm ± 15 mm, Flow rate (3 bar): 25 l/min
Single lever bathtub mixer for exposed installation, CE5230000010 Chrome, Connection type for water supply connection: S-connections, Centre distance: 150 mm ± 15 mm, Flow rate (3 bar): 25 l/min
Single lever bathtub mixer for exposed installation, CE5230000010 Chrome, Connection type for water supply connection: S-connections, Centre distance: 150 mm ± 15 mm, Flow rate (3 bar): 25 l/min
Single lever bathtub mixer for exposed installation, CE5230000010 Chrome, Connection type for water supply connection: S-connections, Centre distance: 150 mm ± 15 mm, Flow rate (3 bar): 25 l/min
Single lever bathtub mixer for exposed installation, CE5230000010 Chrome, Connection type for water supply connection: S-connections, Centre distance: 150 mm ± 15 mm, Flow rate (3 bar): 25 l/min
Single lever bathtub mixer for exposed installation, CE5230000A10 Asian markets only, Chrome, Connection type for water supply connection: S-connections, Flow rate (3 bar): 15,5 l/min
Single lever bathtub mixer for exposed installation, CE5230000A10 Asian markets only, Chrome, Connection type for water supply connection: S-connections, Flow rate (3 bar): 15,5 l/min
Single lever bathtub mixer for exposed installation, CE5230000
Single lever bathtub mixer for exposed installation, CE5230000
Single lever bathtub mixer for exposed installation, CE5230000
Single lever bathtub mixer for exposed installation, CE5230000
Single lever bathtub mixer for exposed installation, CE5230000
Single lever bathtub mixer for exposed installation, CE5230000
Item may differ from picture. Decorations and accessories are not included.
Số hiệu sản phẩm CE5230000
Dimension of connection hose: 1/2", Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter valve
Design by Duravit
Dimension
290 x 201 mm
Variants
Colors
Color Chrome (10)

Smart technology

AirPlus
The water is enriched with air in the jet regulator. The result is a full, soft spray, with reduced water consumption.
Facebook
Twitter
E-Mail
Yêu thích
Suitable accessories for CE5230000010
Hand shower 1jet
#UV0650013
Spray mode: Rain, Dimensions of water supply connection: 1/2", Silicone nubs
Hand shower 1jet MinusFlow
#UV0652013
MinusFlow, Spray mode: Rain, Dimensions of water supply connection: 1/2", Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 1jet
#UV0650014
Spray mode: Rain, Dimensions of water supply connection: 1/2", Silicone nubs
Hand shower 1jet MinusFlow
#UV0652014
MinusFlow, Spray mode: Rain, Dimensions of water supply connection: 1/2", Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet
#UV0650015
Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Silicone nubs
Hand shower 3jet MinusFlow
#UV0652015
MinusFlow, Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet
#UV0650016
Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Silicone nubs
Hand shower 3jet MinusFlow
#UV0652016
MinusFlow, Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet Click!
#UV0650017
Spray mode: Rain, Pulse, Mono, Dimensions of water supply connection: 1/2", Spray mode selection: Push button, Silicone nubs
Hand shower 3jet Click! MinusFlow
#UV0652017
MinusFlow, Spray mode: Rain, Pulse, Mono, Dimensions of water supply connection: 1/2", Spray mode selection: Push button, Flow rate (3 bar): 9 l/min, Silicone nubs
Stick hand shower 1jet
#UV0640001
Dimensions of water supply connection: 1/2", Silicone nubs
Stick hand shower
#UV0642001
MinusFlow, Rain, Flow rate (3 bar): 9 l/min, Silicone nubs
Stick hand shower 1jet
#UV0640002
Dimensions of water supply connection: 1/2", Silicone nubs
Stick hand shower
#UV0642002
MinusFlow, Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower holder
#UV0620001
Material: ABS, Hand shower holder: Fixed, Mounting bracket shape: Conical
Shower hose
#UV0610006
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Shower hose
#UV0610007
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Shower hose
#UV0610008
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Hand shower holder
#UV0620007
Material: Brass, Hand shower holder: Fixed, Escutcheon shape: Round, Mounting bracket shape: Conical
Hand shower holder
#UV0620026
Material: Brass, Hand shower holder: Fixed, Escutcheon shape: Square, Mounting bracket shape: Conical
