White Tulip Single lever bathtub mixer for concealed installation

Single lever bathtub mixer for concealed installation, WT5210012010
Single lever bathtub mixer for concealed installation, WT5210012010
Single lever bathtub mixer for concealed installation, WT5210012010
Single lever bathtub mixer for concealed installation, WT5210012010
Single lever bathtub mixer for concealed installation, WT5210012010
Single lever bathtub mixer for concealed installation, WT5210012010
Single lever bathtub mixer for concealed installation, WT5210012
Single lever bathtub mixer for concealed installation, WT5210012
Item may differ from picture. Decorations and accessories are not included.
Số hiệu sản phẩm WT5210012
Artisan Lines
This product is part of the Duravit Artisan Lines – the design series that demand an exacting degree of know-how, craftsmanship and maximum precision.
Number of outlets: 2, Chrome, Connection type for water supply connection: Basic Set, Ceramic cartridge, Consumer selection: Tub filler, Hand shower, Outlet/Diverter: Diverter valve, Number of outlets: 2, recommended operating pressure: 1 - 5 bar, Flow rate (3 bar): 22,5 l/min, Escutcheon shape: Round, Diameter escutcheon: 170 mm, Including functional unit, Including trim parts
Design by Philippe Starck
Dimension
170 x 97 mm
Variants
WT5210012010
Colors
Color Chrome (10)
Facebook
Twitter
E-Mail
Yêu thích
Necessary accessory
Basic Set
#GK0900001
Shut-off valve: Yes
Basic Set
#GK0900000
Dimensions of water supply connection: DN 15, Shut-off valve: No
Suitable accessories
Bath spout
#C15240009
Spout reach: 205 mm
Bath spout
#C15240010
Spout reach: 205 mm
Hand shower 1jet
#UV0650013
Spray mode: Rain, Dimensions of water supply connection: 1/2", Silicone nubs
Hand shower 1jet MinusFlow
#UV0652013
MinusFlow, Spray mode: Rain, Dimensions of water supply connection: 1/2", Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 1jet
#UV0650014
Spray mode: Rain, Dimensions of water supply connection: 1/2", Silicone nubs
Hand shower 1jet MinusFlow
#UV0652014
MinusFlow, Spray mode: Rain, Dimensions of water supply connection: 1/2", Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet
#UV0650015
Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Silicone nubs
Hand shower 3jet MinusFlow
#UV0652015
MinusFlow, Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet
#UV0650016
Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Silicone nubs
Hand shower 3jet MinusFlow
#UV0652016
MinusFlow, Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet Click!
#UV0650017
Spray mode: Rain, Pulse, Mono, Dimensions of water supply connection: 1/2", Spray mode selection: Push button, Silicone nubs
Hand shower 3jet Click! MinusFlow
#UV0652017
MinusFlow, Spray mode: Rain, Pulse, Mono, Dimensions of water supply connection: 1/2", Spray mode selection: Push button, Flow rate (3 bar): 9 l/min, Silicone nubs
wall outlet
#UV0630009
Round, Non-return valve: Individually, in the hose connection, Escutcheon shape: Round, Dimensions of water supply connection: DN 15
wall outlet
#UV0630010
Square, Non-return valve: Individually, in the hose connection, Escutcheon shape: Square, Hand shower holder: Fixed, Dimensions of water supply connection: DN 15
Shower hose
#UV0610006
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Shower hose
#UV0610007
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Shower hose
#UV0610008
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
