Manhattan Single lever bathtub mixer for concealed installation

Single lever bathtub mixer for concealed installation, MH5210012010 Chrome, Consumer selection: Hand shower, Tub filler, 150x173 mm
Single lever bathtub mixer for concealed installation, MH5210012010 Chrome, Consumer selection: Hand shower, Tub filler, 150x173 mm
Single lever bathtub mixer for concealed installation, MH5210012010 Chrome, Consumer selection: Hand shower, Tub filler, 150x173 mm
Single lever bathtub mixer for concealed installation, MH5210012046 Black Matt, Consumer selection: Hand shower, Tub filler, 150x173 mm
Single lever bathtub mixer for concealed installation, MH5210012
Single lever bathtub mixer for concealed installation, MH5210012
Single lever bathtub mixer for concealed installation, MH5210012
Item may differ from picture. Decorations and accessories are not included.
Số hiệu sản phẩm MH5210012
Number of outlets: 2, Connection type for water supply connection: Basic Set, Ceramic cartridge, Consumer selection: Tub filler, Hand shower, Outlet/Diverter: Diverter valve, Number of outlets: 2, recommended operating pressure: 1 - 5 bar, Escutcheon shape: Square, Including functional unit, Including trim parts
Design by Duravit
Dimension
150 x 82 mm
Variants
Colors
Color Chrome (10)
Color Black Matt (46)
Facebook
Twitter
E-Mail
Yêu thích
Necessary accessory for MH5210012010
Basic Set
#GK0900000
Dimensions of water supply connection: DN 15, Shut-off valve: No
Basic Set
#GK0900001
Shut-off valve: Yes
Suitable accessories
Hand shower 1jet
#UV0650013
Spray mode: Rain, Dimensions of water supply connection: 1/2", Silicone nubs
Hand shower 1jet MinusFlow
#UV0652013
MinusFlow, Spray mode: Rain, Dimensions of water supply connection: 1/2", Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet
#UV0650015
Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Silicone nubs
Hand shower 3jet MinusFlow
#UV0652015
MinusFlow, Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet Click!
#UV0650017
Spray mode: Rain, Pulse, Mono, Dimensions of water supply connection: 1/2", Spray mode selection: Push button, Silicone nubs
Hand shower 3jet Click! MinusFlow
#UV0652017
MinusFlow, Spray mode: Rain, Pulse, Mono, Dimensions of water supply connection: 1/2", Spray mode selection: Push button, Flow rate (3 bar): 9 l/min, Silicone nubs
wall outlet
#UV0630009
Round, Non-return valve: Individually, in the hose connection, Escutcheon shape: Round, Dimensions of water supply connection: DN 15
wall outlet
#UV0630010
Square, Non-return valve: Individually, in the hose connection, Escutcheon shape: Square, Hand shower holder: Fixed, Dimensions of water supply connection: DN 15
Shower hose
#UV0610006
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Shower hose
#UV0610007
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Shower hose
#UV0610008
Rotation lock: Yes, Dimensions of water supply connection: 1/2", Nut shape: Conical
Bath spout
#MH5240010
Escutcheon shape: Square, Dimensions of water supply connection: DN 15
Hand shower 1jet
#UV0650014
Spray mode: Rain, Dimensions of water supply connection: 1/2", Silicone nubs
Hand shower 1jet MinusFlow
#UV0652014
MinusFlow, Spray mode: Rain, Dimensions of water supply connection: 1/2", Flow rate (3 bar): 9 l/min, Silicone nubs
Hand shower 3jet
#UV0650016
Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Silicone nubs
Hand shower 3jet MinusFlow
#UV0652016
MinusFlow, Spray mode: SoftRain, Rain, IntenseRain, Dimensions of water supply connection: 1/2", Spray mode selection: Rotating blasting disc, Flow rate (3 bar): 9 l/min, Silicone nubs
