DuraSystem® Installation element for urinal
Installation element for urinal, WD3004000000
Item may differ from picture. Decorations and accessories are not included.
Số hiệu sản phẩm
WD3004
Powder-coated, Type of installation: In standard lightweight construction, In front of solid wall, Type of mounting: Drywall, Height with feet: 240 mm, Flush operation: Mechanical, Electronic, Flush operation position: Front, Material of cross bars: Wood, Suitable for panelling with plasterboards, Meter marking, Center marker, Height adjustable cross bars: 240 mm, Incl. drain pipe clamp DN 50, Incl. plinth legs, Incl. HT- outlet bend DN 50, Incl. mounting accessories for single installation, Incl. mounting accessories for lightweight construction, Inkl. schallgedämmte Wandscheiben G1/2"
Design by Duravit
Dimension
500 x 170 mm
Variants
Colors
Suitable products
Installation accessories
The flexible solution for every project
Installation frames and actuator plates
In front of the wall: Original Duravit Design. Behind the wall: DuraSystem®. With the new installation frames, Duravit offers reliable and convenient in-wall technology for toilets and urinals. While the high-grade actuator plates are visible.
